QSM11-C400-IV Industrial Engine

XCEC QSM11-C400-IV Industrial engine is a 6-cylinders in line, 10.8 liter four-strokes engine with 125 mm bore and 147 mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes withTurbocharged and Charge Air Cooled

The prime power at 2100 RPM of XCEC QSM11-C400-IV Industrial engine is 400 HP.

As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of XCEC QSM11-C400-IV Industrial Engine

  • Electronic control technology effectively solves the problems of engine running, loading and turning, white smoke, etc.; at the same time, the three-stage fuel filter is used to better protect the engine fuel system, and systematically improve the reliability and durability of the engine.

  • The integrated design of “one piece with multiple functions” makes the number of parts and components less than about 25 % less than that of the same type of engine, fewer connections, and higher engine reliability. The main bearing area is about 30 % than that of the same type of engine, which can guarantee the engineering The machine still has a long working life under high-load working conditions.

  • Compared with the same type of engine, the torque reserve coefficient is larger and the power is stronger, which can meet various complex working conditions.

  • Turbocharger with wastegate valve, effectively improving engine power reserve and transient response.

  • Better environmental adaptability After a large number of severe environmental tests such as plateaus, high heat, high humidity, and extreme cold, it can easily cope with various extreme working conditions.

Technical Specifications

Engine Model:QSM11-C400-IV
Engine Type:6 Cylinders, in Line
Displacement:10.8 L
Rated Speed:2000 RPM
Rated Power / Speed:400 HP @ 2100 RPM
Peak Torque:1898 N.m @ 1400 RPM
Fuel System:Celect Electronic
Aspiration Method:Turbocharged and Charge Air Cooled
Emission Standard:EU Stage IIIA
Bore * Stroke:125 mm * 147 mm
Packing Size(L * W * H):N/A
Weight , Net Dry:N/A
Lead Time:15 – 30 Working Days
Payment Terms:T/T ,L/C

coming soon


Engine ModelEngine SpeedOutput PowerTorqueCompression RatioFuel System
QSM11- C2902100 RPM290 HP983 N.m16.3 : 1Celect Electronic
 QSM11-C290-II2100 RPM 290 HP1478 N.m16.3 : 1Celect Electronic
QSM11-C3002100 RPM300 HP1017 N.m16.3 : 1Celect Electronic
 QSM11-C300-II2000 RPM300 HP1575 N.m16.3 : 1Celect Electronic
QSM11-C300-III2100 RPM300 HP1424 N.m16.3 : 1Celect Electronic
QSM11-C3152100 RPM315 HP1068 N.m16.3 : 1Celect Electronic
 QSM11-C3302100 RPM330 HP1674 N.m16.3 : 1Celect Electronic
QSM11-C3352100 RPM335 HP1036 N.m16.3 : 1Celect Electronic
QSM11-C335-II2100 RPM335 HP1674 N.m16.3 : 1Celect Electronic
 QSM11-C335-III2000 RPM335 HP1790 N.m16.3 : 1Celect Electronic
QSM11-C335-IV2100 RPM335 HP1674 N.m16.3 : 1Celect Electronic
QSM11-C335-V2100 RPM335 HP1674 N.m16.3 : 1Celect Electronic
QSM11-C3401800 RPM340 HP1345 N.m16.3 : 1Celect Electronic
QSM11-C3451900 RPM345 HP1710 N.m16.2 : 1Celect Electronic
QSM11-C350A2100 RPM350 HP1186 N.m16.3 : 1Celect Electronic
QSM11-C350B2000 RPM350 HP1246 N.m16.3 : 1Celect Electronic
QSM11-C350-II2000 RPM350 HP1830 N.m16.3 : 1Celect Electronic
 QSM11-C3601800 RPM360 HP1708 N.m16.3 : 1Celect Electronic
QSM11-C360A1800 RPM360 HP1424 N.m16.3 : 1Celect Electronic
QSM11-C360B2100 RPM360 HP1220 N.m16.3 : 1Celect Electronic
QSM11-C3752100 RPM375 HP1272 N.m16.3 : 1Celect Electronic
QSM11-C375-II2000 RPM375 HP1898 N.m16.3 : 1Celect Electronic
 QSM11-C375-III2100 RPM375 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C3851900 RPM385 HP1835 N.m16.2 : 1Celect Electronic
QSM11-C4002100 RPM400 HP1356 N.m16.3 : 1Celect Electronic
 QSM11-C400-II2000 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-III2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-IV2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-V2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-VI2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-VII2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-VIII2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11-C400-IX2100 RPM400 HP1898 N.m16.3 : 1Celect Electronic
QSM11- C4201900 RPM420 HP1898 N.m16.2 : 1Celect Electronic
General Infomation of XCEC QSM11-C400-IV  Industrial Engine
Engine ModelQSM11-C400-IVCPL Code8471
Curve & DatasheetFR20003Rated Power400 BHP (298 kW) @ 2100 RPM
Compression Ratio16.3 : 1Torque Peak1,400 lb-ft (1,898 N-m) @ 1400 RPM
Noise Emissions Top Side101.4 dBaRevision25-Jan-06
Noise Emissions Right Side104.1 dBaDisplacement660 in3 (10.8 L)
Noise Emissions Left Side104.2 dBaFuel SystemCelect Electronic
Noise Emissions Front Side104.6 dBaMaximum low idle speed1,200 RPM
Exhaust noise emissions121 dBaMinimum low idle speed600 RPM
AspirationTurbocharged and Charge Air CooledMinimum engine speed for full load sustained operation1600 RPM
ConfigurationD353020CX03Emission CertificationU.S. EPA Tier 3, CARB Tier 3, EU Stage IIIA


Torque OutputPower OutputFuel Consumption


Engine Performance Data XCEC QSM11-C400-IV Industrial Engine
 Rated PowerMaximum PowerTorque Peak
Engine Speed2,100 RPM1,800 RPM 1,400 RPM
Output Power400 hp 298 Kw446 hp333 kW373 hp278 kW
Torque1,000 lb-ft1,356 N-m 1,301 lb-ft1,764 N-m1,400 lb-ft1,898 N-m
Motoring Power 61 hp46 kW45 hp33 kW28 hp21 kW
Intake Manifold Pressure62 in-Hg208 kPa66 in-Hg223 kPa64 in-Hg216 kPa
Turbo Comp. Outlet Pressure65 in-Hg 219 kPa69 in-Hg223 kPa66 in-Hg223 kPa
Turbo Comp. Outlet Temperature374 deg F190 deg C384 deg F196 deg C396 deg F202 deg C
Inlet Air Flow1,039 ft3/min490 L/s965 ft3/min455 L/s774 ft3/min365 L/s
Charge Air Flow75 lb/min34 kg/min 70 lb/min32 kg/min56 lb/min25 kg/min
Exhaust Gas Flow2,579 ft3/min1,217 L/s 2,554 ft3/min1,205 L/s2,179 ft3/min1,028 L/s
Exhaust Gas Temperature 915 deg F491 deg C984 deg F529 deg C1,081 deg F583 deg C
Maximum Fuel Flow to Pump423 lb/hr192 kg/hr369 lb/hr167 kg/hr257 lb/hr117 kg/hr
Heat Rejection to Coolant6,663 BTU/min117.16 kW6,918 BTU/min121.65 kW6,022 BTU/min105.89 kW
Heat Rejection to Fuel238 BTU/min4.19 kW238 BTU/min4.19 kW234 BTU/min4.11 kW
Heat Rejection to Ambient1,650 BTU/min29.01 kW1,734 BTU/min 30.49 kW1,494 BTU/min26.27 kW
Heat Rejection to Exhaust 17,050 BTU/min299.81 kW17,440 BTU/min306.67 kW15,400 BTU/min270.8 kW
Steady State Smoke1.23 Bosch 0.56 Bosch0.46 Bosch


System Technical Data of XCEC QSM11-C400-IV Industrial Engine
Intake Air SystemMaximum allowable air temperature rise over ambient at intake manifold (naturally aspirated engines) or turbo compressor inlet (turbo-charged engines): *This parameter impacts emissions, LAT, and/or altitude capability 30 delta deg F16.7 delta deg C
Charge Air Cooling SystemMaximum intake manifold temperature at 25 deg C (77 F) ambient140 deg F60 deg C
Maximum allowable pressure drop across charge air cooler and OEM CAC piping (IMPD): 3 in-Hg10 kPa
Maximum Intake Manifold Temperature Differential (Ambient to IMT) (IMTD): 63 delta deg F35 delta deg C
Intake manifold temperature for Fan-ON 140 deg F60 deg C
Maximum coolant temperature for engine protection controls215 deg F102 deg C
Maximum coolant operating temperature at engine outlet (max. top tank temp):212 deg F100 deg C
Exhaust SyetemMaximum exhaust back pressure:3 inHg10.1 kPa
Recommended exhaust piping size (inner diameter): 5 in127 mm
Lubrication SystemNominal operating oil pressure minimum low idle15 psi103 kPa
 Nominal operating oil pressure maximum rated speed35 psi241 kPa
Minimum engine oil pressure for engine protection devices minimum low idle10 psi69 kPa
Fuel SystemFuel cooling requirements (with diesel fuel)
Maximum heat rejection to return fuel at max. coolant and inlet fuel temperature:260 BTU/min4.57 kW
@ fuel return flow rate of:587 lb/hr266 kg/hr
@ fuel return temperature prior to cooler: 212 deg F100 deg C
Maximum supply fuel flow606 lb/hr275 kg/hr
Maximum return fuel flow587 lb/hr266 kg/hr
Engine fuel compatibility (consult Service Bulletin #5411406 for appropriate use of other fuels) DF1, DF2
Maximum fuel inlet pressure:10 psi 69 kPa
Performance DataMaximum low idle speed1,200 RPM
Minimum low idle speed600 RPM
Minimum engine speed for full load sustained operation1600 RPM
Cranking System(Cold Starting Capability)Unaided Cold Start:
Minimum cranking speed: 110 RPM
Minimum ambient temperature for unaided cold start 10 deg F-12.2 deg C
Cranking torque at minimum unaided cold start temperature215 lb-ft292 N-m
Aided Cold Start:
Minimum ambient temperature with Grid Heater only -10 deg F-23 deg C
Minimum ambient temperature with Ether only-10 deg F-23 deg C
Minimum ambient temperature with coolant and lube heater only0 deg F-18 deg C
Cold starting aids availableEther, Intake Manifold Heater, Block Heater, Oil Pan Heater

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

What's the Standard Scopes of Supply?

With full ranges of emission standard from Euro 2 to Euro 7, Dongfeng Cummins producing 12 series industrial engines, started from 3.9 liter engine, to 15 liter engine, covering the power range of 125HP to 650HP.
Dongfeng Cummins industrial engine customize developing configurations for big vehicle OEMs in China, based on each of requirement, Dongfeng Cummins producing dozens of different configuration engines with same engine model number, which only SO-Shop Order will be different with each other, the SO number is the identify number of the engine configuration of each model.
Even with same engine model, different SO number engine can have very different configuration with each other, with different prices. Some of SO-Shop Order is not available for commercial market, such as restricted models (Usually for military specifications).
EMAC offering most common, cost effective models which also able to process the production in Dongfeng Cummins, which usually have following accessories as standard configuration.


Scopes of Supply of DCEC Industrial Engine

Fuel System1. Fuel Transfer Pump Exhuast System1. Exhuast Manifold
2. High-Pressure Fuel Pump2. Turbocharger
3. Fuel Filter3. Exhuast Elbow
Air Intake System1. Air Intake Manifold Starting System1. Starter Motor
2. N/A2. Starter Rely
Cooling System1. Water Pump Power Output System1. Flywheel
2. Engine Fan2. Standard Flywheel Housing
3. Standard Radiator3. N/A
Lubricating System1. Oil Pump Charging System1. Charging Alternator
2. Oil Filter2. N/A
Engine Shut-Down System1. Engine Fuel Shut-Off Solenoidr Engine Mounting System1. Engine Mouting Bracket
Engine Auiliary Accessories1. Air Compressor

What's the Available Optional Items?

Dongfeng Cummins only provides customize service for the large quantity orders or large OEMs, which means usually the order quantity are higher than 1000 units. For the small quantity engine project, EMAC provides customize services with our own resource and engineer team.
EMAC have rich experience on the customize developing, which provides abundant optional items based on the requirement of each project. The typical optional items are special Prestolite charging alternator, prestolite starter motor, Knorr Air compressor. Valeo air conditioning compressor, ECU output socket set, engine accelerate pedal etc.


Optional Accessories of DCEC Industrial Engine

Air Intake System1. Air Intake Pre-Heater Exhuast System1. Muffler & Bellows
2. Air Intake Shut-Off Valve2. Flame Trap
3. Air Filter3. Spark Arrestor Type Muffler & Bellows
4. Air Intake Pre-Filter4. Dpf System
5. Air Filter Alarm System5. N/A
Fuel System1. Coarse Filter Lubricating System1. Oil Pre-Heater.
2. Fuel Pre-Heater 2. N/A
Starting System1. Manual Magnetic Dc Contactor Cooling System1. Silent Type Radiator
2. Dual Ears Flywheel Housing2. Plateau Radiator
3. Spring Starter Motor3. Salt-Spray Resistant Radiator
4. Air Starter Motor4. Coolant Pre-Heater
5. Hydraulic Starter Motor5. Jacket Water Heater
6. Manual Magnetic Dc Contactor6. N/A
Engine Auiliary Accessories1. Hydraulic Oil Pump Control System1. Can Add Engine Monitoring System, Contro System With Wiring Harness.
2. Air Conditioner Compressor 2. Can Add Self-Protection System that Integrated with Alarm System.
Power Output System1. Clutch Engine Mounting System1. Shock Absorber Pad

Committed to Providing Stable and Reliable Premiem Power System for Global Construction Machinery Manufacturer Partners, ConeMac is A Sub-Brand of the EMAC Group that Focuses on Construction Equipment Application.ConeMac's Ranges of Products Mainly Inclduing Marine Construction Engines Power Pack, Construction Equipment Gearbox, Gear Reducer, Explosion-Proof Engines, Generator Set and Water Pump Set for Mining, Oil and Gas Field.For More Information of Our Industrial Power System Products, You Are Welcome to Visit ConeMac Homepage:

What's the Modifiable Items and Scopes?

As explained in the standard scopes of supply, Dongfeng Cummins not able to provide customize developing for small quantity projects or small OEMs, so EMAC helps SME OEMs to provide customize services, not only providing additional optional items, but also provides customize modification services to meet their requirements based on the exisiting engine SO number.
As flexible service ability is our core advantages, EMAC is very experienced and good at providing customize services, the common customize services are as below:
1: AIr Intake System: Change the air intake direction.
2: Air Exhuast System: We are able to change the turbocharger direction as the interaction on installation could be occured, also change change the air exhuast direction.
3: Lubricating System: Modify lubricating system is one of the most common requirement from customer, we can provide flat-type engine oil pan, to lower down total engine height, which usually required for special vehicles. For the standard engine oil pan, we also can change the direction of the engine oil pan.
4: Cooling System: There are lots of options for the engine cooling system, for the engine fan, we can provide customize for the material of engine fan (plastic fan or steel fan), wind direction of the engine fan (blower fan or suction fan ) and types of engine fan (mechanical fan or electric control fan).
5: Power Output System: Most of electronic controlled Dongfeng Cummins industrial engines are comes with SAE#1 flywheel housing now, while lots of customers need SAE#2 flywheel because of the housing of transmissio is SAE#2, so we have to provide customzie services for those customer, which need to modify flywheel housing, flywheel and starter motor, we also have PTO integrated type flywheel housing available, which can output the whole power of the engine from the PTO on the flywheel housing, we can also provide modification of the mounting side of the starter motor.
6: Electric System: All of Dongfeng Cummins engines are comes with standard 24V electric system, while some customer need to modify the electric system into 12V, we can also modify the starter motor and alternator into appointed brand or appointed specifications.
EMAC is your reliable professional power system partner, feel free to contact our services team to get detailed information about our standard scopes of supply, optional items and modifiable parts for our Dongfeng Cummins industrial engine, we are ready to explore the journey of our cooperation.

How to Order Engine to Replace Your Old Engine?

There are three types of engine replacements demand, type A is to replace the old Dongfeng Cummins engine, the original engine is produced by Dongfeng Cummins, type B is to replace Cummins engine produced in other countries including UK, USA, Mexico, India or Japan Komatsu Cummins, type C is to replace other brands engine or even gasoline engines with Dongfeng Cummins produced engines. The detailed introduction and replacement process are as below:
Type A: Engine Replacement Requirement (Original Engine is Dongfeng Cummins Engine).
This is most simple demand case, you just need to provide us the original engine name plate, and then we can easily check and confirm what exactly you need, and we also ensuring that the engine from us will be 100% same with your original engine. (In some case that the vehicle manufacturing modify the engine on their own, we are not able to supply the parts or the condition that modified by the vehicle manufacturer)
Type B: Engine Replacement Requirement (Original Engine is Cummins Engine but produced in UK, USA or other Cummins engine plant).
EMAC have rich experiences in replace the UK, USA or other engine plant produced engine, with Dongfeng Cummins produced Cummins engines, we required the original engine name plate photo to obtain the related information (at least we will need engine serial number, with engine model name only is useless for us, we are not able to provide quotation with engine model name only for the replacement project), and then we can check out the BOM list and all accessories of your original engine serial number, and then we can check and compare with the BOM list of our Dongfeng Cummins produced engine, choose the most closest SO number engine, and modify the parts that not same with your original engine, we have delivered hundreds of cases of replace the customer's original engine that produced in Cummins UK, USA or other engine plants with Dongfeng Cummins produced engines, you can refer to our video introduction on Youtube:
We can NOT guarantee the engine produced by Dongfeng Cummins is exactly same with your original engine, but we can guarantee that all of engines from EMAC will have no problem with installtion and performance, which all of engines can works very well after replacement.
Type C: Engine Replacement Requirement (Original Engine is other brnad engines even gasoline engines).
EMAC also have rich experiences in replace the engine that not Cummins installed, these engines can be other brands such as Deutz, Caterpillar, Perkins, Komatsu or others, we even had experiences of replace gasoline engine with Dongfeng Cummins produced diesel engines.
This kind of appliaction is more complex and quite risky, EMAC can't do much thing due to lacking of information, the only thing we can guarantee is the performance after replacement, we check and compare the engine performance curve of original engine and our Dongfeng Cummins engine, and then we select the most suitable model for replacement. Due to we are lacking of the installation spaces and related accessories, we will send the both CAD and 3D drawing for our recommend engine model, and then customer have to evaluate the risky of replace the original engine with our engine, especially the risky of space, the possibile interactive when installation, and the risky of modify related coolant pipe, air pipes and wiring harness. Normally this kind of request consuming lots of energy and resource for us to carry on, also quite risky for us, so we will not work on the replacement quantity that below 50 units.
When your requirement is replacement, please tell our customer service team of what type of replacement you need, and provide us original engine name plate, the engine name plate is the necessary material before we start our business negotiations, we will NOT reply to all inquiry that even can't provide engine name plate.

How to Choose the Right Dongfeng Cummins Industrial Engine for You?

To choose a suitable engine for truck, bus or special vehicle manufacturer is quite simple, because the buyer is the manufacturer, so usually they are quite flexible with space, pipes and wiring connections.
The following process are the standard process for us to select a suitable engine model for truck, bus or special vehicle manufacturer demand.
Step 1: We need basic information of the required engine, including rated power, rated speed and emission standard of the required engine.
Step 2: EMAC will evaluate the requirement and select the suitable engine model for customer, with engine data sheet, engine performance curve, CAD darwing, 3D model and budgetary quotation provided back to customer.
Step 3: Customer should check and compare the engine data sheet, performance curve and related drawing and confirm all details one by one. Most important thing is confirm the performance curve suitable for the requirement.
Step 4: After engine confirmed, we have to check and confirm the specifications of accessories one by one carefully, like the electric system specifications (12V or 24V), the detailed specifications of starter motor, charging alternator, air compressor, power steering pump, A/C compressor etc.
Step 5: Confirming the accessories positions and connections, customer need to check and confirm all positions are suitable for the project, such as engine fan, turbocharger, oil pan position, and connections of air pipe, coolant pipe, wiring harness etc.
Step 6: After confirming the engine performance, position, connection and specifications of all accessories, we will be able to provide accurate quotation for prototype and batch order. Prototype is strongly recommend to start the cooperation, to avoid the possible problem, risky on the engine with batch order.
1: Technical support including technical training, onsite installation and commissioning services are avaiable with additional chargers.
2: We are able to supply complete powertrain system, including engine, transmission, transfer, axle, suspension etc, engine with transmission is highly recommended, because if we supply both engine and transmission, we can run simulations for the vehicle, which we usually will provide customer a simulation report, with the simulated result of Balanced Maximum Vehilce Speed and Maximum Grade Ability at different speed.
3: EMAC able supply complete chassis that integrate all powertrain system together, which can greatly reduce the manufacturer's design works and reduce the system mismatching risky.

Tips of Dongfeng Cummins Industrial Engines!

Dongfeng Cummins is one of 50:50 joint venture of Cummins in China, its official Cummins factory that following high Cummins USA production and quality control standard, the Dongfeng Cummins factory swap every 5 years between appointed employee from Dongfeng Motor and Cummins. For more details, you can refer to the company introduction of DCEC-Dongfeng Cummins Engine Company.

Started the production of Cummins engines in China in 1980s, Cummins products has been in China for over 40 years, thousands of people have worked for Cummins China and some of them are very skilled experienced engineer, some of them resigned from Cummins to set up their own small workshops or assembly factories that focusing on producing copy Cummins engines.

Price is always not the problem for Chinese suppliers, there are many tickies to lower down the engine prices, such as supply self-rebuild engine as new engine, supply official RECON engine from Cummins as brand new engine, assembly the fake engine with after-market parts, supply lower power model engine and change the name plate etc. You can find plenty of suppliers on with various prices, the classic Chinese business style is tell you that he give you very low price and not make profit, how can you believe a businessman will make business that have no profit? They gave you low price not becuase they share their profit to you?
As a matter of fact, Chinese supplier often make their profit much more higher by selling the low quality copy products as genuine brand new products! Always remember YOU GET WHAT YOU PAID!
The key point of dealing with Chinese supplier, is to find and choose reliable business partner that will not cheat you for short-term business, but with vision of build long-term career and life-time partnership, EMAC is one of the reliable partner that not chasing for short-term high profit, but we cares our decades of good reputation and we working with all business partners not as supplier and customers, but as close friend and brothers.

FAQ of Dongfeng Cummins Industrial Engines?

1: What mean by DCEC?
DCEC is the short name of Dongfeng Cummins Engine Company, take the first letter of each word, it comes with DCEC as short name, for more details about DCEC, you can refer to the company introduction of DCEC-Dongfeng Cummins Engine Company.

2: Does your engines copy products?
This question is quite often from customer that not familiar with Cummins, Cummins have over 20 joint ventures in China now, and 6 of them are engine joint venture, which Cummins owns 50% share of all of those 6 engine plants, so all of the Cummins factories in China are genuine Cummins factory, that following high Cummins USA production and quality control standard. EMAC is the business partner of DCEC, and we are supplying powertrain and engine power pack based on genuine brand new engines from Dongfeng Cummins for all different applications, EMAC is a reliable and professional power system solution provider that offering abundant various options.
3: Why there are so many companies selling Cummins engines?
There are plenty of companies selling Cummins engines in China, especially on the B2B platform, such as, you can find plenty suppliers there with attractive prices, Cummins products has been in China for over 40 years, thousands of people have worked for Cummins China and some of them are very skilled experienced engineer, some of them resigned from Cummins to set up their own small workshops or assembly factories that focusing on producing copy Cummins engines. You should be careful of being cheated by the attractive prices with copy or rebuild products.
4: How can I identify if the engine genuine or not?
Cummins keep working on the updating its identification system, technically, there are serial number on all key components of Dongfeng Cummins engines, including cylinder block, cylinder head, turbochager, fuel pump, starter motor, alternator, you can collecting the serial number (NOT part number), and then call DCEC call service center to identify if all the numbers are matching to the original number or not. EMAC continuously updating the latest Cummins identification system, you are welcome to following our website or keep in touch with our customer services team to get latest information from Cummins.
5: What's the warranty policy for the engines supplied by EMAC?
EMAC following standard Dongfeng Cummins warranty policy, which will update sometimes, you can following us to get the latest warranty policy from Dongfeng Cummins. Generally EMAC only afford the defective parts cots and shipping costs for the warranty claims, labor costs and transportation costs are not covered in the warranty.
However, EMAC is building our own independant after-sales service system now, which aims to build a global service network, with resouces of global repair and engineering network, which we believe can bring all business partner benifit in future, helping all of OEM manufacturers expanding their market into global market without worries of lacking after-sales service network. For more details about our Global Service, you can visiting
6: How about the future parts supply for the engines? Are you able to supply parts?
As the support team of EMAC's business scope, PartMac is our own brand that focusing on genuine parts directly from all brand factories.
All of EMAC’s partners are facing big challenges with sourcing original spare parts in China. Committed to providing truthworthy and professional after-sales support and parts supply, PartMac is a sub-brand of EMAC group that focusing on parts business. Stick to original parts only, PartMac can’t give any solution on CHEAP PARTS, but you don’t need to worry about any quality issues with every single parts from PartMac.
The picture of Sale Manual showing the accessories and scopes of supply.

Engine Sale Manual

The picture of Installation Drawing showing the accessories and scopes of supply.

Installation Drawing

The picture of Installation Manual showing the accessories and scopes of supply.

Installation Manual

The picture of Operation Manual showing the accessories and scopes of supply.

Operation Manual

The picture of Engine Parts Catalogue showing the accessories and scopes of supply.

Parts Catalogue

The picture of Test Report and Certifcate showing the accessories and scopes of supply.

Report & Certifcate

WhatsApp Online logo

Sales Team

Marine Service - SeaMacWhatApp-Icon

Automotive Service - DuraMacWhatApp-Icon

Industrial Service - ConeMacWhatApp-Icon

Generator Service -SinoGenWhatApp-Icon

Pump Service - PumpMacWhatApp-Icon

Parts Service - PartMacWhatApp-Icon

Sales Manager - Mrs. Wendy Fu

Sales Director - Mr. Jasper Lee       WhatApp-Icon

Shipping Service

Contact EMAC Now!

Subscribe To Our Newsletter

Subscribe To Our Newsletter

Subscribe to get the latest updates from

Welcome on board, we will keep you updated with latest news and business activities!

Pin It on Pinterest
