DCEC QSM11-C300 Industrial Engine

DCEC QSM11-C300 Industrial engine is a 6-cylinders in line, 10.8 liter four-strokes engine with 125mm bore and 147mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes with turbocharger and Air- Air Intercooler.

The prime power at 2100RPM of DCEC QSM11-C300 Industrial engine is 300HP.

As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of DCEC QSM11-C300 Industrial Engine

  • Electronic control technology effectively solves the problems of engine running, loading and turning, white smoke, etc.; at the same time, the three-stage fuel filter is used to better protect the engine fuel system, and systematically improve the reliability and durability of the engine.

  • The integrated design of “one piece with multiple functions” makes the number of parts and components less than about 25% less than that of the same type of engine, fewer connections, and higher engine reliability. The main bearing area is about 30% than that of the same type of engine, which can guarantee the engineering The machine still has a long working life under high-load working conditions.

  • Compared with the same type of engine, the torque reserve coefficient is larger and the power is stronger, which can meet various complex working conditions.

  • Turbocharger with wastegate valve, effectively improving engine power reserve and transient response.

  • Better environmental adaptability After a large number of severe environmental tests such as plateaus, high heat, high humidity, and extreme cold, it can easily cope with various extreme working conditions.

Technical Specifications

Engine Model:QSM11-C300
Engine Type:6 Cylinders, in Line
Displacement:10.8 L
Rated Speed:2100 RPM
Rated Power / Speed:224 kW @ 2100 RPM
Peak Torque:1424 N.m @ 1400 RPM
Fuel System:Celect Electronic
Aspiration Method:Turbocharged & Air-Air Intercooler
Emission Standard:EU Stage IIIA
Packing Size(L*W*H):N/A
Weight , Net Dry:N/A
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C

Engine Model

Engine Speed

Output Power


Compression Ratio

Fuel System

QSM11-C2902100 RPM216 kW983 N.m16.3:1Celect Electronic
QSM11-C3002100 RPM224 kW1017 N.m16.3:1Celect Electronic
QSM11-C3152100 RPM235 kW1068 N.m16.3:1Celect Electronic
QSM11-C3352100 RPM250 kW1036 N.m16.3:1Celect Electronic
QSM11-C3401800 RPM254 kW1345 N.m16.3:1Celect Electronic
QSM11-C350A2100 RPM261 kW1186 N.m16.3:1Celect Electronic
QSM11-C350B2000 RPM261 kW1246 N.m16.3:1Celect Electronic
QSM11-C360A1800 RPM268 kW1424 N.m16.3:1Celect Electronic
QSM11-C360B2100 RPM268 kW1220 N.m16.3:1Celect Electronic
QSM11-C3752100 RPM280 kW1272 N.m16.3:1Celect Electronic
QSM11-C4002100 RPM298 kW1356 N.m16.3:1Celect Electronic

General Infomation of XCEX QSM11-C300 Industrial Engine

Engine ModelQSM11-C300Emission StandardEU Stage IIIA
Curve&DatasheetFR20022Displacement10.8 L
Compression Ratio16.3:1Packing Size(L*W*H)N/A
No. Of Cylinders6 Cylinders, in LineWet WeightN/A
Fuel SystemCelect ElectronicCPL Code Revision8545
AspirationTurbocharged & Air-Air IntercoolerConfigurationD353020CX03
Rated Power300 HP @ 2100 RPMPeak Torque1424 N.m @ 1400 RPM

Performance Data of XCEX QSM11-C300 Industrial Engine

Max. Low Idle Speed1200 RPM
Min. Low Idle Speed600 RPM
Min. Engine Speed for Full Load Sustained Operation1600 RPM

Noise Emissions Data of XCEX QSM11-C300 Industrial Engine

Estimated Free Field Sound Pressure Level At 15 M (50 Ft.) And Full-Load Governed Speed(Excludes Noise From Intake, Exhaust, Cooling System And Driven Components)—Top100.4 dBa
Estimated Free Field Sound Pressure Level At 15 M (50 Ft.) And Full-Load Governed Speed(Excludes Noise From Intake, Exhaust, Cooling System And Driven Components)—Right Side103.2 dBa
Estimated Free Field Sound Pressure Level At 15 M (50 Ft.) And Full-Load Governed Speed(Excludes Noise From Intake, Exhaust, Cooling System And Driven Components)—Left Side103.0 dBa
Estimated Free Field Sound Pressure Level At 15 M (50 Ft.) And Full-Load Governed Speed(Excludes Noise From Intake, Exhaust, Cooling System And Driven Components)—Front103.9 dBa
Estimated Free Field Sound Pressure Level At 15 M (50 Ft.) And Full-Load Governed Speed(Excludes Noise From Intake, Exhaust, Cooling System And Driven Components)—Rear115.0 dBa

Performance Data Rated Power of XCEX QSM11-C300 Industrial Engine

Rated PowerMax. PowerTorque Peak
Engine Speed2100 rmp1800 rmp1400 rmp
Output Power300 HP,224 kW335 HP,250 kW280 HP,209 kW
Torque750 lb-ft,1017 N.m977 lb-ft,1,325 N.m1,050 lb-ft,1,424 N.m
Friction Horsepower61 HP,46 kW45 HP,33 kW28 HP,21 kW
Intake Manifold Pressure43 in-Hg,153 kPa50 in-Hg,167 kPa46 in-Hg,155 kPa
Turbo Comp. Outlet Pressure49 in-Hg,164 kPa52 in-Hg,174 kPa48 in-Hg,161 kPa
Turbo Comp. Outlet Temperature308 deg F,153 deg C325 deg F,163 deg C319 deg F,159 deg C
Inlet Air Flow872 ft3/min,412 L/s794 ft3/min,375 L/s635 ft3/min,300 L/s
Charge Air Flow63 lb/min,29 kg/min56 lb/min,26 kg/min46 lb/min,21 kg/min
Exhaust Gas Flow2,088 ft3/min,985 L/s2,118 ft3/min,1.000 L/s1,717 ft3/min,810 L/s
Exhaust Gas Temperature867 deg F,464 deg C956 deg F,513 deg C1,026 deg F,552 deg C
Max. Fuel Flow to Pump430 lb/hr,195 kg/hr356 lb/hr,161 kg/hr253 lb/hr,115 kg/hr
Heat Rejection to Coolant5,403 BTU/min,95.01 kW5,263 BTU/min,92.55 kW4,762 BTU/min,83.74 kW
Heat Rejection to Fuel222 BTU/min,3.9 kW167 BTU/min,2.94 kW207 BTU/min,3.64 kW
Heat Rejection to Ambient1,233 BTU/min,21.68 kW1,192 BTU/min,20.96 kW1,273 BTU/min,22.38 kW
Heat Rejection to Exhaust12,960 BTU/min,227.89 kW13,431 BTU/min,236.17 kW11,300 BTU/min,198.7 kW
Steady State Smoke0.97 Bosch0.5 Bosch0.23 Bosch

System Technical Data of XCEX QSM11-C300 Industrial Engine

Intake Air SystemMax. Allowable Air Temperature Rise Over Ambient At Intake Manifold (Naturally Aspirated Engines) Or Turbo Compressor Inlet (Turbo-Charged Engines)30 °F , 16.7
Charge Air Cooling SystemMax. Intake Manifold Temperature At 25 Deg C (77 F) Ambient140 deg F , 60 deg C
Max. Allowable Pressure Drop Across Charge Air Cooler And OEM CAC Piping (Impd)4 in-Hg /14 kPa
Max. Intake Manifold Temperature Differential (Ambient To Imt) (Imtd)63 deg F , 35
Intake Manifold Temperature For Fan-On140 deg F , 60 deg C
Max. Coolant Temperature For Engine Protection Controls223 deg F , 106 deg C
Max. Coolant Operating Temperature At Engine Outlet (Max. Top Tank Temp)220 deg F , 104 deg C
Exhaust SystemMax. Exhaust Back Pressure:3 in-Hg /10.1 kPa
Recommended Exhaust Piping Size (Inner Diameter)5 in-Hg / 127 mm
Lubrication SystemNominal Operating Oil Pressure – Min. Low Idle15 psi , 103 kPa
Nominal Operating Oil Pressure – Max. Rated Speed35 psi , 241 kPa
Min. Engine Oil Pressure For Engine Protection Devices – Min. Low Idle10 psi , 69 kPa
Fuel SystemMax. Heat Rejection To Return Fuel At Max. Coolant And Inlet Fuel Temperature260 BTU/min , 4.57 kW
Max. Heat Rejection To Return Fuel At Max. Coolant And Inlet Fuel Temperature – Fuel Return Flow Rate Of572 lb/hr , 259 kg/hr
Max. Heat Rejection To Return Fuel At Max. Coolant And Inlet Fuel Temperature – Fuel Return Temperature Prior To Cooler212 deg F , 100 deg C
Max. Supply Fuel Flow591 lb/hr , 268 kg/hr
Max. Return Fuel Flow572 lb/hr , 259 kg/hr
Max. Fuel Inlet Pressure10 psi , 69 kPa
Cold Starting SystemUnaided Cold Start – Min. Cranking Speed110 RPM
Unaided Cold Start – Min. Ambient Temperature For Unaided Cold Start10 deg F , -12.2 deg C
Unaided Cold Start – Cranking Torque At Min. Unaided Cold Start Temperature215 lb-ft , 292 N.m
Aided Cold Start – Min. Ambient Temperature With Grid Heater Only-10 deg F , -23 deg C
Aided Cold Start – Min. Ambient Temperature With Ether Only-10 deg F , -23 deg C
Aided Cold Start – Min. Ambient Temperature With Coolant And Lube Heater Only0 deg F , -18 deg C
Cold Starting Aids AvailableEther, Intake Manifold Heater, Block Heater,                  Oil Pan Heater

Scopes of Supply of XCEX QSM11-C300 Industrial Engine

Cooling System1. Water Pump        Exhuast System1. Exhuast Manifold
2. Engine Fan2. Turbocharger
3. Standard Radiator3. Exhuast Elbow
Starting System1. Starter Motor        Fuel System1. Common Rail Fuel System
2. Starter Rely2. Fuel Filter
Lubricating System1. Oil Pump        Power Output System1. Flywheel
2. Oil Filter2. Standard Flywheel Housing
Air Intake System1. Air Intake Manifold        Charging System1. Charging Alternator
Engine Mounting System1. Engine Mouting Bracket        Engine Auiliary Accessories1. Air Compressor
Control System1. Ecu & Sensors

Optional Accessories of XCEX QSM11-C300 Industrial Engine

Air Intake System1. Air Intake Pre-Heater        Exhuast System1. Muffler & Bellows
2. Air Intake Shut-Off Valve2. Flame Trap
3. Air Filter3. Spark Arrestor Type Muffler & Bellows
4. Air Intake Pre-Filter 4. Dpf System
5. Air Filter Alarm System5. N/A
Engine Auiliary Accessories1. Hydraulic Oil PumpControl System1. Can Add Engine Monitoring System, Contro System With Wiring Harness
2. Air Conditioner Compressor2. Can Add Self-Protection System That Integrated with Alarm System
Starting System1. Manual Magnetic Dc ContactorCooling System1. Silent Type Radiator
2. Dual Ears Flywheel Housing2. Plateau Radiator
3. Spring Starter Motor3. Salt-Spray Resistant Radiator
4. Air Starter Motor4. Coolant Pre-Heater
5. Hydraulic Starter Motor5. Jacket Water Heater
6. Remote Starting Function6. N/A
7. Lock Protection Function Of Starter Motor7. N/A
8. Manual Magnetic Dc Contactor8. N/A
Fuel System1. Coarse FilterLubricating System1. Oil Pre-Heater
Power Output System1. ClutchEngine Mounting System1. Shock Absorber Pad

Committed to Providing Stable and Reliable Premiem Power System for Global Construction Machinery Manufacturer Partners, ConeMac is A Sub-Brand of the EMAC Group that Focuses on Construction Equipment Application. ConeMac’s Ranges of Products Mainly Inclduing Marine Construction Engines Power Pack, Construction Equipment Gearbox, Gear Reducer, Explosion-Proof Engines, Generator Set and Water Pump Set for Mining, Oil and Gas Field. For More Information of Our Industrial Power System Products, You Are Welcome to Visit ConeMac Homepage:


Modifiable components of XCEX QSM11-C300 Industrial Engine

Exhuast System        Charging System1. 12V Charging Alternator For 12V Electric System
1. Can Modify Installation Position And Direction Of Turbocharger2. Explosion-Proof Charging Alternator
2. Water-Cooled Turbocharger3. Upgrading To Specified Brand And Speicifications Of Charging Alternator
Power Output System1. Can Modify Size Of Flywheel Housing And FlywheelLubricating System1. Oil Pan Position
2. Dual-Ear Flywheel Housing (For Twin-Starter System)2. Number Of Dipstick
3. Some Of Models Can Modify Flywheel Housing Into Pto Integrated Type3. Position Of Dipstick Can Choose From 6 Positions
4. Engine Have Connecting Port Of Ptos, That Able To Provide Power Output4. Can Modify Oil Filter To Be Remote Installation
Cooling System1. Can Modify Engine Fan Into Blower Fan Or Suction FanEngine Auiliary Accessories1. All Of Auxiliary System Can Choose Specified Brands And Specifications
2. Can Modify Central Position Of Engine Cooling Fan2. Additional Auxiliary Systems Can Be Added For Special Applications
3. Can Choose Type Of Engine Fan From Mechanical Type Or Electric Type3. N/A
Fuel System1. Upgrade To Fuel Fitler That Integrated With Fuel Transfer Pump And Fuel Pre-HearterEngine Mounting System1. Can Modify Engine Mouting Bracket
Control System1. Ecu Can Setting To Different Control Mode, Including Can Communication, Analogue Control, Isc1,Isc2,Isc3 Speed Conrol Mode Etc

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
