QSM11 E3 Industrial
XCEC QSM11 series Industrial engine is a 6-cylinders in line, 11 liter four-strokes engine with 125mm bore and 147mm stroke. XCEC QSM11 series Industrial engine equipped with Electrically Control High-pressure Common Rail. The prime power range of is 216 KW to 298 KW.
To achieve different output, XCEC QSM11 series Industrial engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
XCEC QSM11 series electronic industrial engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard XCEC QSM11 series electronic industrial engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at XCEC.
Advantages of QSM11 Industrial Engine
1. Electronic control technology effectively solves the problems of engine running, loading and turning, white smoke, etc.; at the same time, the three-stage fuel filter is used to better protect the engine fuel system, and systematically improve the reliability and durability of the engine.
2. The integrated design of “one piece with multiple functions” makes the number of parts and components less than about 25% less than that of the same type of engine, fewer connections, and higher engine reliability. The main bearing area is about 30% than that of the same type of engine, which can guarantee the engineering The machine still has a long working life under high-load working conditions.
QSM11 Euro Stage III Industrial Engine
All models of DCEC QSM11 Euro Stage III Industrial Engine.
XCEX QSM11-C290 Industrial Engine
Rated Power:290 HP @ 2100 RPM
Max. Torque: 1478 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C300 Industrial Engine
Rated Power: 300 HP @ 2100 RPM
Max. Torque: 1424 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C335 Industrial Engine
Rated Power: 335 HP @ 2100 RPM
Max. Torque: 1674 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C340 Industrial Engine
Rated Power: 340 HP @ 1800 RPM
Max. Torque: 1708 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C350A Industrial Engine
Rated Power: 350HP @ 2100RPM
Max. Torque: 1776N.m @ 1400RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C350B Industrial Engine
Rated Power: 350 HP @ 2000 RPM
Max. Torque: 1830 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C360A Industrial Engine
Rated Power: 360 HP @ 1800 RPM
Max. Torque: 1708 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C360B Industrial Engine
Rated Power: 360 HP @ 2100 RPM
Max. Torque: 1830 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C375 Industrial Engine
Rated Power: 375 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
DCEC QSM11-C400 Industrial Engine
Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA
