DCEC QSZ13-C450-III Industrial Engine

DCEC QSZ13-C450-III Industrial engine is a 6-cylinders in line, 13 liter four-strokes engine with 130mm bore and 163mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes with turbocharger and Air- Air Intercooler. The prime power for generator set 1900RPM of DCEC QSZ13-C450-III Industrial engine is 335 kW.
As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of QSZ13 Industrial Engine

1.Using XPI ultra-high pressure fuel injection system, the fuel injection pressure is up to 2400bar; through precise combustion control, the lowest specific fuel consumption can reach 186g/kW.h, and the low fuel consumption area is wide and more fuel-efficient.
2.Optimize the configuration of the whole machine, lighter weight and more compact structure, the maximum output power can reach 500 kilowatts, the power is surging.
3.Integral all-steel piston design, cylinder block and crankshaft made of high-strength materials, can withstand super-high explosion pressure of 230bar, rigorous component test verification, higher engine strength, and excellent reliability.

Introduction of QSZ13-C450-III

Engine Model:QSZ13-C450-III
Engine Type:6 Cylinders, in Line
Displacement:13.0 L
Rated Speed:1900 rpm
Aspiration Method:T & C
Emission Standard:N/A
Bore*Storke:130*163mm
Packing Size(L*W*H):N/A
Wet Weight:1245kg
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C
Engine ModelEngine SpeedOutput PowerTorqueBore*StorkeFuel System
QSZ13-C380-III1900r/min286KW1440N.m130*163mmHPCR
QSZ13-C400-III1900r/min298KW1500N.m130*163mmHPCR
QSZ13-C425-II1900r/min316KW1590N.m130*163mmHPCR
QSZ13-C425-III1900r/min316KW1590N.m130*163mmHPCR
QSZ13-C450-II1900r/min335KW1685N.m130*163mmHPCR
QSZ13-C450-III1900r/min335KW1685N.m130*163mmHPCR
QSZ13-C475-II1900r/min354KW1780N.m130*163mmHPCR
QSZ13-C475-III1900r/min354KW1780N.m130*163mmHPCR
QSZ13-C500-II1900r/min372KW1872N.m130*163mmHPCR
QSZ13-C500-III1900r/min372KW1872N.m130*163mmHPCR
QSZ13-C525-II1900r/min391KW1965N.m130*163mmHPCR
QSZ13-C550-II1900r/min410KW2060N.m130*163mmHPCR
QSZ13-C575-II1900r/min429KW2155N.m130*163mmHPCR
——END——



Engine Performance Data Rated Power of DCEC  QSZ13-C450-III Industrial Engine

Rated PowerRated Power
Engine Speed1900r/min1200r/minExhaust Gas Flow39.4kg/min18.8kg/min
Gross Power Output335KW276KWAir to Fuel Ratio29.320
Torque1685N.m2200N.mHeat Rejection to Ambient13kW11kW
Brake Mean EffectivePressure1629kPa2126kPaHeat Rejection to JacketCoolant163kW122kW
Piston Speed10.32m/s6.52m/sHeat Rejection to Exhaust290kW163kW
Friction Horsepower50kW20kWHeat Rejection to Fuel4.89kW3.35kW
Coolant Flow503l/min331l/minHeat Rejection to Aftercooler82kW32kW
Fuel Consumption78.2kg/h53.7kg/hTurbochargerCompressor Outlet233kPa132kPa
Intake Air Flow32.3m3/min15.2m3/minCharge Air Flow38.1kg/min17.9kg/min
Exhaust Gas Temp – DryStack481℃569℃TurbochargerCompressor Outlet189℃144℃

Performance Data of DCEC  QSZ13-C450-III Industrial Engine

Air Induction SystemWhole Air Intake Pipe Size (Recommendatory)200mm
Charge Air Cooler Pipe Size(Recommendatory)115mm
Max. Temperature Rise Between Ambient Air And Engine Air Inlet11.1℃
Max. Temp. Rise Between Engine Air Intake And Intake Manifold30℃
Max. Intake Manifold Temperature (Unable To Result In Performance Loss At Sea Level)60℃
Max. Intake Manifold Temperature For Engine Protection85℃
Max. Intake Air Restriction (Heavy Duty Air Cleaner)—Clean Filter3.2kPa
Max. Intake Air Restriction (Heavy Duty Air Cleaner)—Dirty Filter6.2kPa
Max. Allowable Pressure Drop Across Charge Air Cooler and  OEM CAC Piping (CACDP)13kPa
Exhaust SystemMax. Back Pressure Imposed by Complete Exhaust System13kPa
Max. Allowable Static Bending Moment at Exhaust Outlet Flange19N.m
Exhaust Pipe Size (Recommendatory)130mm
Lubrication SystemOil Pressure @ Idle – Minimum89.6kPa
Typical Oil Pressure Range – Warm Engine207-300kPa
Total System Capacity (Standard Pan)45.42L
Max. Lube Oil Flow to All Accessories7.57L/min
Cooling SystemCoolant Capacity (Engine Only)23.1L
Engine Coolant Circuit Thermostat Opening Temperature82℃
Engine Coolant Circuit Thermostat Fully Open Temperature94℃
Max. Coolant Temperature – Engine Out102℃
Min. Operating Block Coolant Temperature71℃
Max. Coolant Temperature for Engine Protection Controls107℃
Max. Coolant Pressure(exclusive of Pressure Cap; Closed Thermostat at Maximum No Load Speed)407kPa
Min. Pressure Cap Rating at Sea Level103kPa
Max. Coolant Friction Head External to Engine75kPa
Max. Deaeration Time25min
Min. Fill Rate (Low Level Alarm Required for Most Engines)19L/min
Max. Coolant Expansion Space (% Total System Capacity)10%
Min. Coolant Expansion Space (% Total System Capacity)6%
Fuel SystemMax. Allowable Restriction(OEM Point .Clean Filter)13.5kPa
Max. Fuel Drain Restriction (Total Head) Before (or Without) Check Valve27kPa
Min. Fuel Tank Venting Requirement0.2L/s
Max. Fuel Inlet Temperature71℃
Max. Heat Rejection to Return Fuel5.36kW
Max. Design Fuel Flow204kg/h
Electrical SystemSystem Voltage24V
Min. Battery Capacity-cold Soak at -18 C (0 F) —Engine Only Cold Cranking Amperes900CCA
Min. Battery Capacity-cold Soak at -18 C (1 F) —Engine Only Reserve Capacity270min
Cold Start CapabilityMin. Ambient Temperature for Unaided Cold Start15℃
Min. Ambient Temperature for Aided Cold Start (Intake Air Heater)30℃
——END——



Scopes of Supply of DCEC  QSZ13-C450-III Industrial Engine

Fuel System1. Fuel Transfer PumpExhuast System1. Exhuast Manifold
2. High-Pressure Fuel Pump2. Turbocharger
3. Fuel Filter3. Exhuast Elbow
Air Intake System1. Air Intake ManifoldStarting System1. Starter Motor
2. Water-Air Intercooler2. Starter Rely
Cooling System1. Water PumpPower Output System1. Flywheel
2. Engine Fan2. Standard Flywheel Housing
3. Standard Radiator3. N/A
Lubricating System1. Oil PumpCharging System1. Charging Alternator
2. Oil Filter2. N/A
Engine Shut-Down System1. Engine Fuel Shut-Off SolenoidrEngine Mounting System1. Engine Mouting Bracket
Engine Auiliary Accessories1. Air Compressor
——END——



Optional Accessories of DCEC QSZ13-C450-III Industrial Engine

Air Intake System1. Air Intake Pre-HeaterExhuast System1. Muffler & Bellows
2. Air Intake Shut-Off Valve2. Flame Trap
3. Air Filter3. Spark Arrestor Type Muffler & Bellows
4. Air Intake Pre-Filter4. DPF System
5. Air Filter Alarm System5. N/A
Fuel System1. Coarse FilterLubricating System1. Oil Pre-Heater.
2. Fuel Pre-Heater2. N/A
Starting System1. Manual Magnetic Dc ContactorCooling System1. Silent Type Radiator
2. Dual Ears Flywheel Housing2. Plateau Radiator
3. Spring Starter Motor3. Salt-Spray Resistant Radiator
4. Air Starter Motor4. Coolant Pre-Heater
5. Hydraulic Starter Motor5. Jacket Water Heater
6. Manual Magnetic Dc Contactor6. N/A
Engine Auiliary Accessories1. Hydraulic Oil PumpControl System1. Can Add Engine Monitoring System, Contro System With Wiring Harness.
2. Air Conditioner Compressor2. Can Add Self-Protection System that Integrated with Alarm System.
Power Output System1. ClutchEngine Mounting System1. Shock Absorber Pad
——END——



Modifiable Components of DCEC QSZ13-C450-III Industrial Engine

Air Intake System1. Installation Position of Air FilterCharging System1. 12V charging Alternator for 12v Electric System
2. Upgrade to Heavy-Duty Type Air Fitler2. Explosion-Proof Charging Alternator
3. N/A3. Upgrading to Specified Brand and Speicifications of Charging Alternator
Exhuast System1. Water-Cooled TurbochargerLubricating System1. Oil Pan Position
2. Water-Cooled Exhuast Manifold2. Number of Dipstick
3. Can Modify Installation Position And Direction Of Turbocharger3. Position of Dipstick Can Choose from 6 Positions
4. N/A4. Can Modify Oil Filter to be Remote Installation
Engine Shut-Down System1. 12V Solenoid for 12V Electric SystemStarting System1. Upgrading to Specified Brand and Speicifications of Starter Motor
2. Explosion-Proof Solenoid2. 12V Starter Motor for 12v Electric System
Fuel System1. Upgrade to Fuel Fitler that Integrated with Fuel Transfer Pump and Fuel Pre-HearterEngine Auiliary Accessories1. All of auxiliary System can Choose Specified Brands and Specifications.
2. N/A2. Additional Auxiliary Systems Can be Added for Special Applications.
Cooling System1. Can Modify Engine fan Into Blower Fan or Suction FanPower Output System1. Can Modify Size of Flywheel Housing and Flywheel.
2. Can Modify Central Position of Engine Cooling Fan2. Dual-Ear Flywheel Housing (For Twin-Starter System)
3. Can Choose Type of Engine Fan From Mechanical Type or Electric Type3. Some of Models can Modify Flywheel Housing Into PTO Integrated Type.
4. N/A4. Engine Have Connecting Port of PTOs, That Able to Provide Power Output.
Engine Mounting System1. Can Modify Engine Mouting Bracket.
