DCEC EQB210-20B Automotive Engine
DCEC EQB210-20B automotive engine is a 6-cylinders in line, 5.9 liter four-strokes engine with 102mm bore and 120mm stroke, equipped with Bosch P7100(Weifu PW2000) pump. DCEC EQB210-20B automotive engine comes with turbocharger and Air- Air intercooler, with a EURO II post-processor.
The prime power at 2500RPM of DCEC EQB210-20B automotive engine is 210HP.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of EQB210-20B Automotive Engine
Lower fuel consumption: Originated from the United States CMS advanced design and superior manufacture, lower 20% oil consumption than congeneric Chinese products.
Strong power, the design of exhaust bypass valve makes low speed performance more perfect and better dynamic performance.
Excellent reliability, Cylinder block and head using integrated design, to stop the engine leaking and oil leakage phenomenon, engine parts are Less 40% than other similar engine, greatly reduce the failure rate.
Lower maintenance and repair costs, Fewer parts quantity and lower use fault Make the engine comprehensive maintenance cost greatly reduced and maintenance time than similar type save 50%.
Excellent cold start performance, equipped with air suction electric preheater and 6.6 kw power starter, Completely improve the cold start performance of the engine. Through the arctic village-MoHe of China-36。C extreme low temperature validation.
Technical Specifications
| Engine Model: | EQB210-20B |
| Engine Type: | 6 |
| Displacement: | 5.9 L |
| Rated Speed: | 2500 RPM |
| Rated Power: | 210 HP @ 2500 RPM |
| Peak Torque: | 700 N.m @ 1500 RPM |
| Fuel System: | Bosch P7100 / Weifu PW2000 Pump |
| Aspiration Method: | Turbocharged & Air-Air Intercooler |
| Emission Standard: | N/A |
| Bore*Storke: | 102 mm * 120 mm |
| Packing Size(L*W*H): | N/A |
| Wet Weight: | 437 kg |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
Engine Model | Advertised Power | Peak Torque | No. of Cylinders | Displacement | Fuel System |
| EQB125-20 | 125 HP @ 2800 RPM | 410 N.m @ 1500 RPM | 4 | 3.9 L | Bosch Pump |
| EQB140-20 | 140 HP @ 2700 RPM | 502 N.m @ 1500 RPM | 4 | 3.9 L | Bosch Pump |
| EQB160-20 | 160 HP @ 2500 RPM | 565 N.m @1500~1600 RPM | 6 | 5.9 L | BYC P7000 Pump |
| EQB170-21 | 170 HP @ 2500 RPM | 560 N.m @ 1300 RPM | 6 | 5.9 L | BYC P7100/RQV-K Pump |
| EQB180-20A | 180 HP @ 2500 RPM | 610 N.m @ 1500 RPM | 6 | 5.9 L | Bosch Pump |
| EQB180-20B | 180 HP @ 2500 RPM | 610 N.m @ 1500 RPM | 6 | 5.9 L | Bosch P7100 / Weifu PW2000 Pump |
| EQB190-20 | 190 HP @ 2800 RPM | 650 N.m @ 1400 RPM | 6 | 5.9 L | Bosch Pump |
| EQB190-21 | 190 HP @ 2500 RPM | 640 N.m @ 1300-1500 RPM | 6 | 5.9 L | BYC P 7100 Pump |
| EQB210-20A | 210 HP @ 2500 RPM | 700 N.m @ 1500 RPM | 6 | 5.9 L | Bosch Pump |
| EQB210-20B | 210 HP @ 2500 RPM | 700 N.m @ 1500 RPM | 6 | 5.9 L | Bosch P7100 / Weifu PW2000 Pump |
| EQB235-20 | 235 HP @ 2500 RPM | 800 N.m @ 1600 RPM | 6 | 5.9 L | Bosch P7100 Pump |
| ——END—— | |||||
General Infomation of DCEC EQB210-20B Automotive Engine | |||
| Engine Model | EQB210-20B | Advertised Power | 210 HP @ 2500 RPM |
| Peak Torque | 700 N.m @ 1500 RPM | Curve&Datasheet | FR 91317 |
| Fuel System | Bosch P7100 / Weifu PW2000 Pump | No. Of Cylinders | 6 |
| Aspiration | Turbocharged & Air-Air Intercooler | Displacement | 5.9 L |
| Bore*Storke | 102 mm * 120 mm | CPL Code Revision | 8555 |
| Dry Weight | 413 kg | Wet Weight | 437 kg |
| Compression Ratio | 17.3:1 | ||
Installation Data of DCEC EQB210-20B Automotive Engine | |||
| Center of Gravity. Distance From Front Face of Block | 328 mm | ||
| Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) | 155 mm | ||
| Maximum Bending Moment At Rear Face of Block | 1356 N.m | ||
| Maximum Crankshaft Thrust Bearing load limit- Intermittent load | 3781 N | ||
| Maximum Crankshaft Thrust Bearing load limit-Continuous load | 1780 N | ||
| Instantaneous Inertia At Rotating: (Without Flywheel) | 0.25 kg.m2 | ||
| Emissions Certification | GB17691/GB14761 | ||
| Idle Speed | 750 RPM | ||
| Maximum Non-Load Speed | 2850 RPM | ||
| Over Speed Performance (Within 15 Seconds) | 4200 RPM | ||
| The Clutch Torque @ 800Rpm | 450 N.m | ||
| Maximum Altitude At Which Continuous operation Is Allowed | 3000 m | ||
| Supercharger outlet Exhaust Pressure limit Value | 414 kPa | ||
| Maximum Power of Exhaust Brake | 112 kW | ||
| ——END—— | |||
Engine Performance Data Rated power of DCEC EQB210-20B Automotive Drive Engine | |||||
| Rated Power | Torque Peak | Rated Power | Torque Peak | ||
| Engine Speed | 2500 RPM | 1500 RPM | Exhaust Temperature | 550 ℃ | 480 ℃ |
| Oil Pressure | 400 kPa | 350 kPa | Fuel Consumption | 46.7 l/hr | 26.9 l/hr |
| The Air Flow | 18.2 m³/min | 10.1 m³/min | Coolant Flow | 185 l/m | 110 l/m |
| The Flow Rate of Pressurized Air | 21 kg/min | 11.5 kg/min | Heat Loss Coolant | 81 kW | 50 kW |
| Pressurized Air Pressure | 165 kPa | 110 kPa | Heat Loss Air | 37 kW | 19 kW |
| The Exhaust Flow | 51 m³/min | 28 m³/min | Mechanical Loss of Power | 32 kW | 13 kW |
System Technical Data of DCEC EQB210-20B Automotive Drive Engine | ||
| Air Intake System | Maximum Temperature Rise Between Ambient Air and Engine Air Inlet | 15 ℃ |
| Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty | 2.9 (300) kPa (mmH2O) | |
| Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty | 3.7 (380) kPa (mmH2O) | |
| Maximum Intake Restriction with Dirty Filter | 6.2 (635) kPa (mmH2O) | |
| Turbocharged & Intercooled | Maximum Intake Manifold Temperature-Second Level | 55 ℃ |
| Maximum Intake Manifold Temperature-Three-Level | 50 ℃ | |
| Intercooler Cooling Temperature-Second Level | 25 ℃ | |
| Intercooler Cooling Temperature-Three-Level | 20 ℃ | |
| Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level | 16.7 (125) kPa(mmHg) | |
| Minimum Inlet Pipe Diameter Allowed-Three-Level | 75 mm | |
| Exhaust System | Maximum Back Pressure Imposed by Complete Exhaust System | 10.0 (75) kPa (mmHg) |
| Exhaust Pipe Size Normally Accepable | 75 mm | |
| Maximum Static Bend Allowed for Turbocharger Exhaust Flange | N/A | |
| Lubrication System | Low oil Level Inclination Angle-Front Up | 45 ° |
| Low oil Level Inclination Angle-Back Up | 45 ° | |
| Low oil Level Inclination Angle-Fuel Pump Side Up | 45 ° | |
| Low oil Level Inclination Angle-Exhaust Side Up | 45 ° | |
| Oil Sump Capacity-Upper Limit | 14.2 L | |
| Oil Sump Capacity-Lower Limit | 12.4 L | |
| Capacity of The Whole System | 16.4 L | |
| Cooling System | Coolant Capacity – Engine only | 9 L |
| Standard Thermostat (Modulating) Range | 83-95 ℃ | |
| Minimum Fill Rate ( Without Low Level Alarm) | 19 l/min | |
| Minimum Coolant Expansion Space – % of System Capacity | 6% | |
| Water Tank Capacity Without Water Expansion | 6 L | |
| Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) | 276 kPa | |
| Maximum Degassing Time | 25 mins | |
| Maximum Coolant Flow to Accessories | 41 l/min | |
| Maximum Coolant Temperature Engine out | 100 ℃ | |
| Minimum Allows Pressure of Pressure Cap | 50 kPa | |
| Minimum Recommended Coolant Temperature | 70 ℃ | |
| Common Operating Temperature Range of Fans with Fan Clutch | 93 ℃ | |
| Maximum Coolent Temperature For Engine Protection Control | 100 ℃ | |
| The Limit Environmental Temperature at Rated Speed | Second Level 45 ℃;Three-Level 42 ℃ | |
| The Limit Environmental Temperature at Peak Torque | Second Level 40 ℃;Three-Level 37 ℃ | |
| 24V Electrical System | Maximum Allowable Resistance of Cranking Circuit | 0.002 Ω |
| The Cold Start Current When Engine and The Clutch Separate | 12 V 500 24 V 250 | |
| Cold Starting System | Maximum Unaided Cold Start Temperature | 120 RPM -10 ℃ |
| Maximum Aided Cold Start Temperature | 110 RPM -35 ℃ | |
| Fuel System | Maximum Fuel Return Resistance | 520 (mmHg) |
| Maximum Inlet Resistance of oil Pump with Clean Filter | 150 (mmHg) | |
| ——END—— | ||
Scopes of Supply of DCEC EQB210-20B Automotive Engine | ||||
| Air Intake System | 1. Air Intake Manifold | Exhuast System | 1. Exhuast Manifold | |
| 2. Water-Air Intercooler | 2. Turbocharger | |||
| 3. N/A | 3. Exhuast Elbow | |||
| Fuel System | 1. Fuel Transfer Pump | Starting System | 1. Starter Motor | |
| 2. High-Pressure Fuel Pump | 2. Starter Rely | |||
| 3. Fuel Filter | 3. N/A | |||
| Charging System | 1. Charging Alternator | Engine Shut-Down System | 1. Engine Puel Shut-Off Solenoid | |
| Lubricating System | 1. Oil Pump | Cooling System | 1. Water Pump | |
| 2. Oil Filter | 2. Engine Fan | |||
| 3. N/A | 3. Standard Radiator | |||
| Power Output System | 1. Flywheel | Engine Mounting System | 1. Engine Mouting Bracket | |
| 2. Standard Fflywheel Housing | 2. N/A | |||
| Engine Auiliary Accessories | 1. Air Compressor | |||
| 2. Power Steering Pump | ||||
| ——END—— | ||||
Optional Accessories of DCEC EQB210-20B Automotive Engine | ||||
| Air Intake System | 1. Air Intake Pre-Heater | Exhuast System | 1. Muffler & Bellows | |
| 2. Air Intake Shut-Off Valve | 2. Flame Trap | |||
| 3. Air Filter | 3. Spark Arrestor Type Muffler & Bellows | |||
| 4. Air Intake Pre-Filter | 4. DPF System | |||
| 5. Air Filter Alarm System | 5. N/A | |||
| Fuel System | 1. Coarse Filter | Starting System | 1.Manual Magnetic DC Contactor | |
| 2. Fuel Pre-Heater | 2. Dual Ears Flywheel Housing | |||
| 3. N/A | 3. Spring Starter Motor | |||
| 4. N/A | 4. Air Starter Motor | |||
| 5. N/A | 5. Hydraulic Starter Motor | |||
| Lubricating System | 1. Oil Pre-Heater. | Cooling System | 1. Silent Type Radiator | |
| 2. N/A | 2. Plateau Radiator | |||
| 3. N/A | 3. Salt-Spray Resistant Radiator | |||
| 4. N/A | 4. Coolant Pre-Heater | |||
| Power Output System | 1. Clutch | Engine Mounting System | 1. Shock Absorber Pad | |
| Engine Auiliary Accessories | 1. Hydraulic Oil Pump | Control System | 1. Can Add Mechanical Accelerator Pedal | |
| 2. Air Conditioner Compressor | 2. N/A | |||
| 3. N/A | 3. N/A | |||
| ——END—— | ||||
As part of EMAC, DuraMac is Committed to providing reliable powertrain system to commercial vehicle manufacturers around the world, a sub-brand of EMAC group that focusing on automotive application. Based on dozens of world-class engine manufacturing resources in China, and as official exporting agent of Fast tranmission (Joint venture with Caterpillar AT tranmission), Dongfeng Dana axle and Komman air suspension, DuraMac provides one-stop solutions covers from pre-design to components supply, from installation to commissioning, from pre-sales communication to after-sales service support. For more information of our automotive power system products, you are welcome to visit DuraMac homepage: www.duramac.com
Modifiable Components of DCEC EQB210-20B Automotive Engine | ||||
| Air Intake System | 1. Installation Position of Air Filter | Exhuast System | 1. Can Modify Installation Position and Direction of | |
| 2. Upgrade to Heavy-Duty Type Air Fitler | Turbocharger | |||
| 3. N/A | 2. Water-Cooled Exhuast manifold | |||
| 4. N/A | 3. Water-Cooled Turbocharger | |||
| Fuel System | 1. Upgrade to Fuel Fitler That Integrated with Fuel Transfer | Starting System | 1. 12V Starter Motor For 12v Electric System | |
| Pump and Fuel Pre-Hearter | 2. Upgrading to Specified Brand and Speicifications of | |||
| 2. N/A | Starter Motor | |||
| Charging System | 1. 12V Charging Alternator for 12v Electric System | Engine Shut-Down System | 1. 12V Solenoid for 12v Electric System | |
| 2. Explosion-Proof Charging Alternator | 2. Explosion-Proof Solenoid | |||
| 3. Upgrading to Specified Brand And Speicifications of | 3. N/A | |||
| Charging Alternator | 4. N/A | |||
| Lubricating System | 1. Oil Pan Position | Cooling System | 1. Can Modify Engine Fan Into Blower Fan or Suction Fan | |
| 2. Number of Dipstick | 2. Can Modify Central Position of Engine Cooling Fan | |||
| 3. Position of Dipstick Can Choose From 6 Positions | 3. Can Choose Type of Engine Fan From Mechanical Type or | |||
| 4. Can Modify Oil Filter to be Remote Installation | Electric Type | |||
| Power Output System | 1. Can Modify Size of Flywheel Housing and Flywheel. | Engine Mounting System | 1. Can Modify Engine Mouting Bracket. | |
| 2. Dual-Ear Flywheel Housing (for Twin-Starter System) | 2. N/A | |||
| 3. Some of Models Can Modify Flywheel Housing Into PTO | 3. N/A | |||
| Integrated Type. | 4. N/A | |||
| 4. Engine Have Connecting Port of PTOs, That Able to | 5. N/A | |||
| Provide Power Output. | 6. N/A | |||
| Engine Auiliary Accessories | 1. All of Auxiliary System Can Choose Specified Brands and | |||
| Specifications. | ||||
| 2. Additional Auxiliary Systems Can be Added for Special | ||||
| Applications. | ||||
| ——END—— | ||||
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
