DCEC QSB4.5 Industrial Engine

DCEC QSB4.5 series Industrial engine is a 4-cylinders in line, 4.5 liter four-strokes engine with 107mm bore and 124mm stroke. DCEC QSB4.5 series Industrial engine equipped with Electrically Control High-pressure Common Rail. The prime power range of is 81 KW to 119 KW.

To achieve different output, DCEC QSB4.5 series Industrial engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC QSB4.5 series electronic industrial engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC QSB4.5 series electronic industrial engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

Advantages of QSB4.5 Industrial Engine

1. The five key systems of the engine are developed and optimized and integrated by DCEC to ensure the reliability of the engine.

2. High pressure common rail fuel system (HPCR), fuel injection pressure up to 1600bar, rapid throttle response at different speeds, more efficient power output, better fuel economy, and lower noise.
3. The filter system is redesigned for oil products, and the fuel is adaptable and suitable for applications in various fields.
4. New high-strength cylinder design, improved displacement, better reliability, low noise and longer service life.

DCEC QSB4.5 Series Industrial Engine

This is the list of all series of DCEC QSB4.5 Series Industrial Engine.
Click here to find industrial engines by type (Fuel System & Emission Standard).

DCEC QSB4.5-C110D Industrial Engine

DCEC QSB4.5-C110D Industrial Engine

Rated Power: 82 kW @ 1800 RPM
Max. Torque: 488 N.m @1300 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C109 Industrial Engine

DCEC QSB4.5-C109 Industrial Engine

Rated Power: 81 kW @ 2000 RPM
Max. Torque: 461 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C110A Industrial Engine

DCEC QSB4.5-C110A Industrial Engine

Rated Power: 82 kW @ 2200 RPM
Max. Torque: 488 N.m @ 1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C110B Industrial Engine

DCEC QSB4.5-C110B Industrial Engine

Rated Power: 82 kW @ 2200 RPM
Max. Torque: 488 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C110C Industrial Engine

DCEC QSB4.5-C110C Industrial Engine

Rated Power: 82 kW @ 2500 RPM
Max. Torque: 488 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C121 Industrial Engine

DCEC QSB4.5-C121 Industrial Engine

Rated Power: 90 kW @ 2500 RPM
Max. Torque: 470 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C128 Industrial Engine

DCEC QSB4.5-C128 Industrial Engine

Rated Power: 95 kW @ 2000 RPM
Max. Torque: 546 N.m @1400 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C130A Industrial Engine

DCEC QSB4.5-C130A Industrial Engine

Rated Power: 97 kW @ 2200 RPM
Max. Torque: 622 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C130B Industrial Engine

DCEC QSB4.5-C130B Industrial Engine

Rated Power: 97 kW @ 2000 RPM
Max. Torque: 620 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C130C Industrial Engine

DCEC QSB4.5-C130C Industrial Engine

Rated Power: 97 kW @ 1800 RPM
Max. Torque: 542 N.m @1400 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C130D Industrial Engine

DCEC QSB4.5-C130D Industrial Engine

Rated Power: 97 kW @ 2300 RPM
Max. Torque: 512 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C132 Industrial Engine

DCEC QSB4.5-C132 Industrial Engine

Rated Power: 98 kW @ 2000 RPM
Max. Torque: 499 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C139 Industrial Engine

DCEC QSB4.5-C139 Industrial Engine

Rated Power: 104 kW @ 2000 RPM
Max. Torque: 504 N.m @1800 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C140 Industrial Engine

DCEC QSB4.5-C140 Industrial Engine

Rated Power: 104 kW @ 2000 RPM
Max. Torque: 586 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C148 Industrial Engine

DCEC QSB4.5-C148 Industrial Engine

Rated Power: 110 kW @ 2300 RPM
Max. Torque: 598 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C160A Industrial Engine

DCEC QSB4.5-C160A Industrial Engine

Rated Power: 119 kW @ 2500 RPM
Max. Torque: 622 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C160B Industrial Engine

DCEC QSB4.5-C160B Industrial Engine

Rated Power: 119 kW @ 2400 RPM
Max. Torque: 624 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C160C Industrial Engine

DCEC QSB4.5-C160C Industrial Engine

Rated Power: 119 kW @ 2300 RPM
Max. Torque: 624 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III

DCEC QSB4.5-C160D Industrial Engine

DCEC QSB4.5-C160D Industrial Engine

Rated Power: 119 kW @ 2200 RPM
Max. Torque: 624 N.m @1500 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro Stage III
